BIO DUO 100 340K BTU High-Efficiency Wood Chip Boiler

BIO DUO 100 – High-Efficiency Wood Chip Boiler for Commercial Use

The BIO DUO 100 is a modern and efficient boiler designed to provide reliable heating for both residential and industrial applications, with a maximum heating output of 100kW (340K BTU). It is engineered to burn wood chips and waste fuel of any quality, offering a sustainable and versatile solution for your heating needs.

Key Features:

• Heating Capacity: Can efficiently heat up to 10,000 ft².
• Weight: 2,900 lb for durability and stability.
• Fuel Type: Designed to burn woodchip fuel, making it an eco-friendly option.
• Hopper Volume: Choose between a 300 gal hopper that holds 3,000 lb of woodchip, giving you extended autonomy for uninterrupted operation.

Performance & Efficiency:

• Power: The BIO DUO 100 operates with a power range of 30-100 kW (102K - 340K BTU).
• Efficiency: Achieves an impressive 86% efficiency at rated power, ensuring optimal heat recovery from the combusted fuel.
• Exhaust Gas Temperature: The exhaust gas temperature does not exceed 155°C, promoting energy-efficient operation.

Safety & Automation:

• System Safety: Features thermal water protection and a sensor-based fuel line temperature control to prevent fuel ignition in the auto-feed system.
• Manual & Automatic Operation: While it can manually burn wood, you also have the option to choose automatic ash removal and/or automatic igniter systems for added convenience.
• Ignition: The ignition button needs to be pressed and held until the fire starts, after which releasing the button will stop the igniter.

Construction:

• High-Strength Steel: Built using the highest quality ASTM A106 certified boiler steel for durability and strength.
• Thermal Insulation: Equipped with 2" thick non-combustible insulation and thermal protection systems for maximum heat retention and safe operation.
• Powder-Coated Skin: The exterior is powder-coated to resist mechanical stress and maintain long-term durability.

TIS TRONIC 660HD Control System:

• Fan and Feeder Control: Manages the operation of the fan and boiler feeder.
• Pump Control: Controls pumps for central heating (CH), domestic hot water (DHW), and hot water circulation.
• Temperature Control: Monitors the temperature of flue gases and adjusts combustion accordingly.
• Seasonal Modes: Operates in both winter and summer modes for energy efficiency.
• External Temperature Sensor: Adjusts the operation based on outdoor conditions, optimizing heating performance.
• Room Thermostat & Internet Module: Optionally connect a room thermostat and the TIS TRONIC 501 internet module for remote control.

Maintenance & Durability:

• Front Maintenance: All maintenance is performed from the front, ensuring easy access for cleaning and servicing without the need to disassemble components.
• Wide Door Openings: Allows for easy cleaning of the top heat exchanger, biomass loading, and ash removal.
• 10-Year Warranty: A 10-year warranty ensures that the BIO DUO 100 will provide reliable service for many years.

This commercial-grade boiler is made in Europe and is perfect for businesses seeking a robust, efficient, and low-maintenance heating solution.
