Kingsman ZCVRB72 72" Zero Clearance Propane Direct Vent Linear Fireplace

Kingsman ZCVRB72 72" Zero Clearance Propane Direct Vent Linear Fireplace

Transform your living space with the Kingsman 72-Inch Zero Clearance Linear Direct Vent Gas Fireplace. Designed specifically for new construction or home renovation, this elegant fireplace brings both sophisticated warmth and modern style to any room. Its striking linear profile creates a stunning focal point, effortlessly blending contemporary aesthetics with high-performance heating.

Engineered with heavy-duty steel construction, this fireplace offers long-lasting durability without compromising on visual appeal. It comes equipped with tempered glass, a protective safety barrier screen, and decorative bronze fire glass that highlights a lush, realistic flame pattern. Safe, certified, and versatile, this unit is fully approved for installation in bedrooms, bed-sitting rooms, and mobile or manufactured homes.

Experience seamless operation and reliability with the factory-installed Millivolt control system, designed specifically for propane gas. The system requires no electricity to ignite, ensuring continuous, comforting warmth even during power outages. For maximum convenience, the control setup is remote-ready, giving you effortless access to your flame at the push of a button.

Tailor the look to suit your unique interior design. You can further customize your appliance by adding optional features, such as a porcelain reflective liner that deepens the visual illusion of the flame, or by upgrading ignition preferences to match your home’s smart heating needs.

What's Included

• ZCVRB72 Linear Fireplace

• SIT Valve with Hi/Lo Adjustment
• Bronze Glass Media x 3 Bags
• Tempered Glass
• Linear Burner

• Safety Screen
• 5/8" Top Flue


Not Included (Sold Separately)

• Grills for Ventilation
• Surround Trim Kit
• Porcelain Reflective Liner
• Decorative Cannonballs
• Fan Kit With Variable Speed
• Universal Light Kit
• Tile Lip Kit

• Gas Conversion Kit

• Thermostats and Remote Controls

View and Downloads

• Product Guide
• Product Brochure
• Product Manual

Vented Chase Option

The chase of the appliance may be vented to achieve Cool Touch Walls or reduced Mantel Clearances. The following options are available to vent the chase:

• The top of the chase can be left open.
• A grill can be installed on the front of the chase.
• If the chase bumps out into the room, side grills can be installed on each side of the chase.

Minimum enclosure height for a vented chase is measured from bottom of fireplace, ventilation of minimum free air opening is required. Choose between our Enclosure Grills (Front or Sides) or Custom Grill (if custom grills are used the louvers cannot slope) or adequate ventilation opening as stated in the manual. Grill or opening must meet minimum (as specified in the installation manual) of chase top/ceiling.

SPECIFICATIONS WITH OPENINGS (MIN. NO GRILLS)

ZCVRB47 – 105 sq/in.
ZCVRB60 – 200 sq/in.
ZCVRB72 – 285 sq/in.

Min. Enclosure Height
ZCVRB47 – 70”
ZCVRB60 – 76”
ZCVRB72 – 79”

Min. Opening Below Ceiling
ZCVRB47 – 1-1/4”
ZCVRB60 – 1-7/8”
ZCVRB72 – 2-3/8”

SPECIFICATIONS WITH GRILLS (MIN. AIR FREE OPENINGS)

ZCVRB47 – 105 sq/in.
ZCVRB60 – 220 sq/in.
ZCVRB72 – 285 sq/in.

Min. Enclosure Height
ZCVRB47 – 70”
ZCVRB60 – 76”
ZCVRB60 – 79”

Grill Opening (Max. Distance from top of Ceiling)
ZCVRB47 – 2”
ZCVRB60 – 3/4”
ZCVRB60 – 3/4”
